Core Dim (H x W) |
Overall (H x W) |
Hose Locations |
Hose Fittings |
Fill Neck |
Trans Cooler |
Mounting Specs |
Mounting Type |
|
17 1/8" x 21 5/8" |
23 3/8" x 23 5/8" |
In - Center, Out - Passenger |
In - 1 1/2", Out - 1 3/4" |
Yes |
1/2-20 Straight Thread, Inverted Flare |
23 5/8" |
Brackets |
|
|
Application |
Engines |
|
3 Row Core Thickness |
3 Row Tank Thickness |
|
1955 - 1956
Chevrolet Bel Air |
3.8L 235ci L6, 3.9L 235ci L6 |
|
2 1/2" |
3" |
|
1955 - 1956
Chevrolet Nomad |
3.8L 235ci L6, 3.9L 235ci L6 |
|
|
1955-1956
Chevrolet 150 Series |
3.8L 235ci L6, 3.9L 235ci L6 |
|
|
1955 - 1956
Chevrolet 210 Series |
3.8L 235ci L6, 3.9L 235ci L6 |
|
|
|
|
|
|
|
|
|
|
|
