CORE DIM (H x W) |
OVERALL (H x W) |
HOSE LOCATIONS |
HOSE FITTINGS |
TRANS COOLER |
Fill Neck |
MOUNTING TYPE |
BRACKET SPECS |
|
20 x 23 |
26 1/4 x 26 3/4 |
In - Center, Out - Driver |
In - 1 1/2, Out - 1 3/4 |
1/8-27 NPT |
Yes |
Bracket Mount |
Vert - 18 1/2 Horizontal - 24 7/8 |
|
|
APPLICATION |
ENGINES |
|
3 ROW CORE THICKNESS |
3 ROW TANK THICKNESS |
|
Ford Truck 1953 - 56 |
V6, V8 - Doesn't Work On Flat Head |
|
2 1/4" |
3 1/2" |
|
|
2 ROW CORE THICKNESS |
2 ROW TANK THICKNESS |
|
1 1/2" |
2 3/8" |
|
|
4 ROW CORE THICKNESS |
4 ROW TANK THICKNESS |
|
2 3/4" |
Upper - 3 5/16", Lower - 3 1/8" |
|
|
|
|
|
|
|
|
|
