CORE DIM (H x W)
OVERALL (H x W)
HOSE LOCATIONS
HOSE FITTINGS
TRANS COOLER
Fill Neck
MOUNTING TYPE
BRACKET SPECS
20 x 23
26 1/4 x 26 3/4
In - Dual, Out - Dual
In - 1 1/4, Out - 1 3/4
1/8-27 NPT
Yes
Bracket Mount
Vert - 18 1/2 Horizontal - 24 7/8
APPLICATION
ENGINES
3 ROW CORE THICKNESS
3 ROW TANK THICKNESS
Ford Truck 1953-56
V8 Flathead
2 1/4"
3 1/2"
2 ROW CORE THICKNESS
2 ROW TANK THICKNESS
1 5/8"
3 1/2"
