CORE DIM (H x W) |
OVERALL (H x W) |
HOSE LOCATIONS |
HOSE FITTINGS |
TRANS COOLER |
FILL NECK |
MOUNTING TYPE |
BRACKET SPECS |
|
20 5/8 x 19 3/4 |
25 7/8 x 22 1/2 |
In - Passenger, Out - Driver |
In - 1 1/2, Out - 2 |
1/8-27 NPT |
Yes |
Bracket |
21 3/8" |
|
|
Applications |
Engine |
|
Notes: Oversized "Police
Interceptor" Replacement |
|
1954 - 1956
Ford Club |
3.9L 239ci V8, 4.2L 256ci V8, 4.4L 272ci V8, 4.8L 292ci V8, 5.1L 312ci
V8 |
|
|
1954 - 1956
Ford Country Sedan |
3.9L 239ci V8, 4.2L 256ci V8, 4.4L 272ci V8, 4.8L 292ci V8, 5.1L 312ci
V8 |
|
|
1954 - 1956
Ford Country Squire |
3.9L 239ci V8, 4.2L 256ci V8, 4.4L 272ci V8, 4.8L 292ci V8, 5.1L 312ci
V8 |
|
3 Row Core Thickness |
3 Row Tank Thickness |
|
1954 - 1956
Ford Courier Sedan Delivery |
3.9L 239ci V8, 4.4L 272ci V8 |
|
2" |
Upper: 3 1/4", Lower: 2 3/8" |
|
1954 - 1956
Ford Crestline |
3.9L 239ci V8, 4.2L 256ci V8, 4.4L 272ci V8, 4.8L 292ci V8, 5.1L 312ci
V8 |
|
|
1954 - 1956
Ford Customline |
3.9L 239ci V8, 4.2L 256ci V8, 4.4L 272ci V8, 4.8L 292ci V8, 5.1L 312ci
V8 |
|
4 Row Core Thickness |
4 Row Tank Thickness |
|
1954 - 1956
Ford Fairlane |
3.9L 239ci V8, 4.2L 256ci V8, 4.4L 272ci V8, 4.8L 292ci V8, 5.1L 312ci
V8 |
|
2 3/4" |
Upper: 3 1/4", Lower: 3 1/8" |
|
1955 - 1956
Ford Mainline |
3.9L 239ci V8, 4.2L 256ci V8, 4.4L 272ci V8, 4.8L 292ci V8, 5.1L 312ci
V8 |
|
|
1956 Ford
Park Lane Wagon |
4.4L 272ci V8, 4.8L 292ci V8, 5.1L 312ci V8 |
|
|
1954 - 1956
Ford Ranch Wagon |
3.9L 239ci V8, 4.2L 256ci V8, 4.4L 272ci V8, 4.8L 292ci V8, 5.1L 312ci
V8 |
|
|
1954 - 1956
Ford Skyliner |
3.9L 239ci V8, 4.2L 256ci V8, 4.4L 272ci V8, 4.8L 292ci V8, 5.1L 312ci
V8 |
|
|
1954 - 1956
Ford Sunliner |
3.9L 239ci V8, 4.2L 256ci V8, 4.4L 272ci V8, 4.8L 292ci V8, 5.1L 312ci
V8 |
|
|
1954 - 1956
Ford Victoria |
3.9L 239ci V8, 4.2L 256ci V8, 4.4L 272ci V8, 4.8L 292ci V8, 5.1L 312ci
V8 |
|
|
|
|
|
|
|
|
|
|
|
|
