CORE DIM (H x W) |
OVERALL (H x W) |
Hose Locations |
Hose Fittings |
Fill Neck |
Trans Cooler |
Bracket Specs |
|
17 7/8" x 24" |
23 1/4" x 26 3/8" |
In - Passenger, Out - Driver |
In - 1 1/2", Out - 2" |
Yes |
1/8-27 NPT |
Horizontal - 25 3/8" |
|
|
|
|
|
|
|
|
|
Application |
Engine |
|
3 Row Core Thickness |
3 Row Tank Thickness |
|
1957 - 1959
Ford Club |
4.4L v8, 4.8L V8, 5.1L V8, 5.4L V8, 5.8L V8, 5.9L V8 |
|
2" |
Upper - 3 1/4",
Lower - 2 3/8" |
|
1957 - 1959
Ford Country Sedan |
4.4L v8, 4.8L V8, 5.1L V8, 5.4L V8, 5.8L V8, 5.9L V8 |
|
|
|
|
1957 - 1959
Ford Country Sedan |
4.8L V8, 5.1L V8, 5.4L V8, 5.8L V8, 5.9L V8 |
|
2 ROW CORE THICKNESS |
2 ROW TANK THICKNESS |
|
1957 - 1959
Ford Country Squire |
4.8L V8, 5.1L V8, 5.4L V8, 5.8L V8, 5.9L V8 |
|
1 5/8" |
Upper - 3 1/4", Lower - 2 3/8" |
|
1957 - 1959
Ford Courier Sedan Delivery |
4.4L v8, 4.8L V8, 5.8L V8 |
|
|
|
|
1957 Ford
Custom |
4.4L V8, 4.8L V8, 5.1L V8 |
|
4 ROW CORE THICKNESS |
4 ROW TANK THICKNESS |
|
1957 - 1959
Ford Custom 300 |
4.4L v8, 4.8L V8, 5.1L V8, 5.4L V8, 5.8L V8, 5.9L V8 |
|
2 3/4" |
Upper - 3 5/16", Lower - 3 1/8" |
|
1957 - 1958
Ford Del Rio Wagon |
4.4L v8, 4.8L V8, 5.1L V8, 5.4L V8, 5.8L V8, 5.9L V8 |
|
|
|
|
1957 - 1959
Ford Fairlane |
4.4L V8, 4.5L V8, 4.8L V8, 5.1L V8, 5.4L V8, 5.8L V8, 5.9L V8 |
|
|
|
|
1959 Ford
Galaxie |
4.8L V8, 5.4L V8, 5.8L V8, 5.9L V8 |
|
|
|
|
1957 - 1959
Ford Ranch Wagon |
4.4L v8, 4.8L V8, 5.1L V8, 5.4L V8, 5.8L V8, 5.9L V8 |
|
|
|
|
1957 - 1959
Ford Ranchero |
4.4L v8, 4.8L V8, 5.4L V8, 5.8L V8, 5.9L V8 |
|
|
|
|
1957 - 1959
Ford Skyliner |
4.4L v8, 4.8L V8, 5.1L V8, 5.4L V8, 5.8L V8, 5.9L V8 |
|
|
|
|
1957 - 1959
Ford Sunliner |
4.4L v8, 4.8L V8, 5.1L V8, 5.4L V8, 5.8L V8, 5.9L V8 |
|
|
|
|
1957 - 1959
Ford Victoria |
4.4L v8, 4.8L V8, 5.1L V8, 5.4L V8, 5.8L V8, 5.9L V8 |
|
|
|
|
|
|
|
|
|
|
|
|
