CORE DIM (H x W)
OVERALL (H x W)
HOSE LOCATIONS
HOSE FITTINGS
TRANS COOLER
FILL NECK
MOUNTING TYPE
BRACKET SPECS
18 7/8 x 21 3/4
25 x 26 5/8
In - Center, Out - Passenger
In - 1 1/2, Out - 1 3/4
1/2-20 Straight Thread, Inverted Flare
Yes
Bracket Mount
Vert - 12 1/4", Horizontal - 25 1/2"
APPLICATION
3 ROW CORE THICKNESS
3 ROW TANK THICKNESS
Chevy Truck 1960 - 62
2 1/4"
2 1/2"
2 ROW CORE THICKNESS
2 ROW TANK THICKNESS
1 1/2"
2 1/2"
