CORE DIM (H x W)
OVERALL (H x W)
HOSE LOCATIONS
HOSE FITTINGS
TRANS COOLER
FILL NECK
MOUNTING TYPE
BRACKET SPECS
17 1/8 x 22 1/2
20 7/8 x 26 3/4
In - Passenger, Out - Driver
In - 1 3/4", Out - 1 3/4"
1/8-27 NPT
No
Bracket
Vert - 12 1/4", Horizontal - 25 1/2
APPLICATION
3 ROW CORE THICKNESS
3 ROW TANK THICKNESS
60 - 63 Ford Galaxie
2"
2 1/4"
4 ROW CORE THICKNESS
4 ROW TANK THICKNESS
2 3/4"
3 1/8"
