CORE DIM (H x W)
OVERALL (H x W)
HOSE LOCATIONS
HOSE FITTINGS
TRANS COOLER
FILL NECK
MOUNTING TYPE
BRACKET SPECS
16 1/2" x 17 1/4"
21 3/8" x 20"
In - Passenger, Out - Driver
In - 1 1/4, Out - 1 1/4
1/8-27NPT
Yes
Bracket Mount
19"
Application
3 ROW CORE THICKNESS
3 ROW TANK THICKNESS
Econoline 1961 -65 V8
B Core 2 1/2"
2 3/4"
