CORE DIM (H x W)	OVERALL (H x W)	HOSE LOCATIONS	HOSE FITTINGS	FILL NECK	TRANS COOLER	MOUNTING TYPE
	15 1/2 x 24	21 1/2 x 26 1/8	In - Driver, Out - Passenger	In - 1 1/2, Out - 1 3/4	Yes	1/2-20 Straight Thread, Inverted Flare	Bracket Mount
	APPLICATION		Engines			3 ROW CORE THICKNESS	3 ROW TANK THICKNESS
	1963 - 1965 Chevy II Nova		Factory V8 4.6L, 5.3L, 5.4L			2 1/4"	3 1/4"
						4 ROW CORE THICKNESS	4 ROW TANK THICKNESS
						2 3/4	3 5/16"
