Core Dim (H x W)
Overall (H x W)
Hose Locations
Hose Fittings
FILL NECK
Trans Cooler
Bracket
Mounting Type
18" x 19 1/4"
23 1/4" x 26"
In - Passenger, Out - Passenger
In - 1 3/8", Out - 1 3/8"
Yes
1/8-27 NPT
24 3/4"
Bracket Mount
Application
Engines
3 Row Core Thickness
3 Row Tank Thickness
1965 - 1966 Plymouth Valiant
170-2.8L L6, 225-3.7L L6
2 1/4"
2 3/4"
1965 - 1966 Dodge Dart
170-2.8L L6, 225-3.7L L6
Notes
Slant 6 Engine
