Core Dim (H x W) |
Overall (H x W) |
Hose Locations |
Hose Fittings |
Fill Neck |
Trans Cooler |
Mounting Specs |
Mounting Type |
|
21 1/2" x 18 7/8" |
25 7/8" x 22
1/2" |
In -
Center-Passenger, Out - Driver |
In - 1 1/2",
Out - 1 1/2" |
Yes |
1/8-27NPT |
21 1/8" |
Brackets |
|
|
|
|
|
|
|
|
|
|
Application |
Engines |
|
|
|
3 Row Core Thickness |
3 Row Tank Thickness |
|
1964-1966,
1970 Dodge A100 |
4.5L 273ci V8, 5.2L 318ci V8 |
|
|
|
2" |
Upper - 3 3/4",
Lower - 2 3/8" |
|
1964-1970
Dodge A100 Truck |
4.5L 273ci V8, 5.2L 318ci V8 |
|
|
|
|
|
|
NOTE: Upper Passenger Side Inlet |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
