CORE DIM (H x W)
OVERALL (H x W)
HOSE LOCATIONS
HOSE FITTINGS
TRANS COOLER
MOUNTING TYPE
BRACKET SPECS
16 1/2 x 17 1/8
21 5/8 x 19 5/8
In - Center, Out - Driver
In - 1 1/2, Out - 1 3/4
1/8-27 NPT
Bracket Mount
Horizontal - 10 1/4
APPLICATION
ENGINES
3 ROW CORE THICKNESS
3 ROW TANK THICKNESS
1966-77 Ford Bronco
W/ 6 CYL
2 1/4"
2 1/2"
