Core Dim (H x W) |
Overall (H x W) |
Hose Locations |
Hose Fittings |
Fill Neck |
Trans Cooler |
Mounting Specs |
Mounting Type |
|
|
|
17 1/2" x 22" |
22 3/4" x 25 1/4" |
In: Center Driver, Out - Driver |
In - 1 1/2", Out - 1 1/2" |
Yes |
1/8-27 NPT |
24" |
Brackets |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Application |
Engines |
|
|
3 Row Core Thickness |
3 Row Tank Thickness |
|
|
|
1967 - 1969
Dodge Dart |
4.5L/273ci V8, 5.2L/318ci V8, 5.6L/340ci V8 |
|
|
2 1/4" |
Upper - 3 1/2", Lower - 2 1/2" |
|
|
|
1967 - 1969
Plymouth Valiant |
4.5L/273ci V8, 5.2L/318ci V8, 5.6L/340ci V8 |
|
|
|
|
|
|
|
1967 - 1969
Plymouth Barracuda |
4.5L/273ci V8, 5.2L/318ci V8, 5.6L/340ci V8 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
