Core Dim (H x W) |
Overall (H x W) |
Hose Locations |
Hose Fittings |
Fill Neck |
Trans Cooler |
Mounting Specs |
Mounting Type |
|
|
17 1/2" x 19 1/8" |
19 3/4" x
24" |
Dual Passenger |
In & Out - ORB -
16 |
Yes |
N/A |
5/16-18 |
Bung |
|
|
|
|
|
|
|
|
|
|
|
|
Application |
Engines |
|
|
|
2 Row Core Thickness |
2 Row Tank Thickness |
|
|
1964-1968
Ford Country Sedan |
4.3L 260ci V8, 4.7L 289ci V8, |
|
|
|
2 1/4" |
2 7/8" |
|
|
5.0L 302ci V8, 5.8L 352ci
V8, |
|
|
|
|
|
|
|
6.4L 390ci V8, 7.0L 427ci
V8, |
|
|
|
|
|
|
|
7.0L 428ci V8 |
|
|
|
|
|
|
|
1964-1968
Ford Country Squire |
4.3L 260ci V8, 4.7L 289ci
V8, |
|
|
|
|
|
|
|
5.0L 302ci V8, 5.8L 352ci
V8, |
|
|
|
|
|
|
|
6.4L 390ci V8, 7.0L 427ci
V8, |
|
|
|
|
|
|
|
7.0L 428ci V8 |
|
|
|
|
|
|
|
1963-1969
Ford Fairlane |
3.6L 221ci V8, 4.3L 260ci
V8, |
|
|
|
|
|
|
|
4.7L 289ci V8, 5.0L 302ci
V8, |
|
|
|
|
|
|
|
5.8L 351ci V8, 5.8L 352ci
V8, |
|
|
|
|
|
|
|
6.4L 390ci V8, 7.0L 427ci
V8, |
|
|
|
|
|
|
|
7.0L 428ci V8 |
|
|
|
|
|
|
|
1966-1970
Ford Falcon |
4.7L 289ci V8, 5.0L 302ci
V8, |
|
|
|
|
|
|
|
5.8L 351ci V8, 7.0L 429ci V8 |
|
|
|
|
|
|
|
1964-1967
Ford Galaxie |
4.3L 260ci V8, 4.7L 289ci
V8, |
|
|
|
|
|
|
|
5.8L 352ci V8, 6.4L 390ci
V8, |
|
|
|
|
|
|
|
7.0L 427ci V8, 7.0L 428ci V8 |
|
|
|
|
|
|
|
1967-1968
Ford LTD |
4.7L 289ci V8, 5.0L 302ci
V8, |
|
|
|
|
|
|
|
5.8L 352ci V8, 6.4L 390ci
V8, |
|
|
|
|
|
|
|
7.0L 427ci V8, 7.0L 428ci V8 |
|
|
|
|
|
|
|
1967-1970
Ford Mustang |
4.7L 289ci V8, 5.0L 302ci
V8, |
|
|
|
|
|
|
|
5.8L 351ci V8, 6.4L 390ci
V8, |
|
|
|
|
|
|
|
7.0L 427ci V8, 7.0L 428ci
V8, |
|
|
|
|
|
|
|
7.0L 429ci V8 |
|
|
|
|
|
|
|
1967-1969
Ford Ranchero |
5.0L 302ci V8, 5.8L 351ci
V8, |
|
|
|
|
|
|
|
6.4L 390ci V8, 7.0L 428ci V8 |
|
|
|
|
|
|
|
1968-1969
Ford Torino |
5.0L 302ci V8, 5.8L 351ci
V8, |
|
|
|
|
|
|
|
6.4L 390ci V8, 7.0L 427ci
V8, |
|
|
|
|
|
|
|
7.0L 428ci V8 |
|
|
|
|
|
|
|
1967-1970
Mercury Cougar |
4.7L 289ci V8, 5.0L 302ci
V8, |
|
|
|
|
|
|
|
5.8L 351ci V8, 6.4L 390ci V8, |
|
|
|
|
|
|
|
7.0L 427ci V8, 7.0L 428ci V8, |
|
|
|
|
|
|
|
7.0L 429ci V8 |
|
|
|
|
|
|
|
NOTE: Fits
Ford V8 motors with Passenger Side Outlet and Chevy LS Conversions |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
