Core Dim (H x W) |
Overall (H x W) |
Hose Locations |
Hose Fittings |
Fill Neck |
Trans Cooler |
Mounting Specs |
Mounting Type |
|
17 7/8" x 24 3/8" |
19 7/8" x 30 1/8" |
In - Passenger, Out - Driver |
In - 1 1/2", Out - 1 3/4" |
Yes |
1/4-18NPT |
N/A |
Saddle Mount |
|
|
|
|
|
|
|
|
|
|
Application |
Engines |
|
|
3 Row Core Thickness |
3 Row Tank Thickness |
|
1968
Lincoln Continental |
7.0L 429ci v8, 7.5L 460ci v8, 7.6L 462ci V8 |
|
|
2" |
Driver - 3 1/4", Passenger - 2 5/8" |
|
1969
Lincoln Continental |
7.5L 460ci v8 |
|
|
|
|
|
Note: Does not fit a 1968-69 Continental
"Mark III". |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
