CORE DIM (H x W)
OVERALL (H x W)
HOSE LOCATIONS
HOSE FITTINGS
Fill Neck
TRANS COOLER
MOUNTING TYPE
20 1/4 x 23
26 1/2 x 26 1/2
In - Center, Out - Passenger
In - 1 1/2, Out - 1 3/4
Yes
1/2-20 Straight Thread, Inverted Flare
Bracket Mount
APPLICATION
ENGINES
3 ROW CORE THICKNESS
3 ROW TANK THICKNESS
1953 -56 Ford Truck
Chevy Configuration
2 1/4"
3 1/4"
