Core Dim (H x W)
Overall (H x W)
Hose Locations
Hose Fittings
Fill Neck
Trans Cooler
Bracket
Mounting Type
15 1/8" x 29 7/8"
23 1/4" x 30 1/2"
In - Driver, Out - Passenger
In - 1 3/8", Out - 1 3/8"
Yes
9/16-18 UNF
N/A
Pins
Application
Engines
3 Row Core Thickness
3 Row Tank Thickness
2010 - 2011 Chevrolet Camaro
6.2L/376ci V8
2"
2 1/2"
2 Row Core Thickness
2 Row Tank Thickness
1 1/2"
2 1/2"
4 Row Core Thickness
4 Row Tank Thickness
2 3/4"
3 1/8"
