Core Dim (H x W) |
Overall (H x W) |
Hose Locations |
Hose Fittings |
Fill Neck |
Trans Cooler |
Mounting Specs |
Mounting Type |
|
18 1/2" x 22 3/4" |
24 5/8" x 29
7/8" |
In - Passenger, Out
- Driver |
In - 1 3/8",
Out - 1 5/8" |
Yes |
5/8-18 UNF Male |
N/A |
OEM Mounting |
|
|
|
|
|
|
|
|
|
|
Application |
Engines |
|
|
|
1 Row Core Thickness |
1 Row Tank Thickness |
|
2009 - 2012 Chevrolet Colorado |
5.3L 325ci V8 |
|
|
|
1 5/8" |
1 7/8" |
|
2009 - 2011 GMC Canyon |
5.3L 325ci V8 |
|
|
|
|
|
|
2006 - 2010 Hummer H3 |
3.5L 211ci L5, 3.7L 223ci L5 |
|
|
|
|
|
|
5.3L 325ci V8 |
|
|
|
|
|
|
2009 - 2010 Hummer H3T |
5.3L 325ci V8 |
|
|
|
|
|
|
Note:
For Automatic Transmission Only. |
|
|
|
|
|
|
|
|
|
|
|
|
Note: This radiator does not come with a
radiator cap. You will need to purchase the correct "screw on"
radiator cap for your specific vehicle. |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
