Core Dim (H x W)
Overall (H x W)
Hose Locations
Hose Fittings
Fill Neck
Trans Cooler
Mounting Specs
Mounting Type
22" x 26 5/8"
22 5/8" x 35 5/8"
In - Driver, Out - Passenger
In - 1 3/4", Out - 1 3/4"
No
M20-1.5
34 1/8"
Brackets
Application
Engines
2 Row Core Thickness
2 Row Tank Thickness
2013 - 2018 Ram 2500
6.7L 408ci L6
1 5/8"
2 1/4"
2013 - 2018 Ram 3500
6.7L 408ci L6
2013 Ram 4000
6.7L 408ci L6
2013 - 2018 Ram 4500
6.7L 408ci L6
2013 - 2018 Ram 5500
6.7L 408ci L6
Note: Main Radiator For Automatic Transmission
